BRAND | PAVONE SISTEMI |
Product | PSMC0007 / MC 302 |
Description | Digital Weight Indicator |
Internal code | IMP4008962 |
Technical specification | MC 302 digital weight indicator Basic version Maximum supply of 8 350 ohm cells. Zero tracking function. Alarm management and weight control Red LED display, digit height 14 mm, Maximum 7 digit display. Maximum viewable divisions 600000 (10000 divisions in the approved version). No. 6 relay outputs (max 115Vac/30Vcc, 0.5A each). No. 8 optoisolated logic inputs 12Vcc/24Vcc PNP. No. 2 serial ports: RS232C and RS422/485 for the connection to PC, PLC, printer or remote display. Fully programmable from the keyboard. 230 Vac +/ -10% supply (115 Vac on request), 50/60 Hz. Optional 12 to 24 VDC power supply. Operating temperature -10°C ÷ +50°C. Storage temperature -20°C ÷ +70°C. EMI-RFI jamming protection. Polycarbonate container. Panel mount. |
Please Contact Us to Order to offer competitive prices and delivery time for PAVONE SISTEMI - PSMC0007 / MC 302 Digital Weight Indicator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
