| BRAND | Steimel |
| Product | T 2 - 70 GGK |
| Description | Pump |
| Internal code | IMP4746262 |
| Weight | 10 |
| Technical specification | Gear pump: T 2 - 70 GGK in accordance with Directive 2014/34/EU (ATEX) Item number (pump): BT2-A016R Dimension sheet: DPP002-A016R Spare part list: DET002-A016R Operating manual: DBA-ZP02 DBA-ZP-ATEX-01 Suction and pressure connection: G 1 Body parts: EN-GJL-250 (EN-JL 1040) Drive and counter sprocket: 16 MnCrS5, hardened, straight-toothed Shaft seal: GLRD M 37GN/15+G16+K+R Sealing quench template: GLRD M 2/15+K+L GLRD elastomers: Kalrez ATEX quench tank Item No.: BQB---ATEX--XC01 pressureless Type: QB 1000 Container capacity: approx. 1 liter Connection thread: G 3/8 Filling hole: G 3/8 Temperature: max. 100°C Pressure: vented Level monitoring: visual (inspection glass) : sealed with Loctite 577 Quenching liquid: on site (materials used check for durability) Material design Container: 1.4301 Vent screw: aluminum Sight glass: natural glass Identification plate: ETY924-QB---PK01 Quenching liquid: on site before commissioning fill in, e.g. alcohol or solvent (optical control via level sticker) temperature monitoring prepared for: 1 cold conductor Item no. YBX416 Bearing bushings: Bronze AW increased bearing clearance: without other elastomers: PTFE Conveying medium: paints and varnishes Viscosity: max. 300 - 5,000 mm2/s Temperature: max. 50 degrees C flow rate: 0 - 700 L/ h Pressure: 0 - 4 bar Speed: 0 - 350 rpm Direction of rotation: right Test run: yes, with HLPD 46 Pre-cleaning: rinse with white spirit Coating: primer HDO058 Silicone-free pump! The pump was tested with mineral oil and must be rinsed before use! Information sign: EAY924-----PL02 ATEX type plate: ETY924-D/E--PE03 ATEX certification: II 2G Exh IIB T3 Gb X Prerequisite for operation: Ex-zone 1, temperature class T3, Ambient temperature -20°C to 40°C Explosion group: IIB (gas) Limit temperature 100°C 1.00 pcs documentation Z-VTP DOCU-ATEX operating instructions, measurement sheet, spare parts list Installation declaration/Declaration of conformity |
Discover the superior quality and performance of the Steimel T 2 - 70 GGK with Impexron GMBH in Malaysia. Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The T 2 - 70 GGK is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of T 2 - 70 GGK:
At Impexron GMBH, we offer the T 2 - 70 GGK at competitive prices and with the fastest delivery times across Malaysia. Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH?
Get Your Quote Today! Ready to enhance your operations with the T 2 - 70 GGK? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
You can purchase :product by :brand from Impexron GMBH.We serve customers across the Malaysia, offering competitive prices and reliable service.
What is the price of :product?
For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.
While we are not the official distributor or seller of :brand in the Malaysia, we source our products from reliable channels and offer you original :brand equipment at competitive prices.
You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.
We can assist you in contacting the manufacturer to ensure you receive the support you need.
