BRAND | Nord |
Product | SK33-100AP/4 TF |
Description | helical gear motor |
Internal code | IMP4750860 |
Custom code | 85015220 |
Technical specification | PREM AL (B) asynchronous motor series Motor type 3-Ph AC Motor AxAB Motor speed 1,450 rpm Translation 17.94 Output speed 81,000 rpm Operating factor 1.40 Output torque M2 (Nm) 354.00 Power (kW) 3,000 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Nominal current 1 (AMP) 10.90 Current Rating 2 (AMP) 6.26 Cosine 1 0.80 M1 gearbox design Case type Foot housing Wave size 40X80 Open vent, with transport lock Thermal motor protection cold conductor, 3x155°C Star circuit type Terminal box layer/cable insert 1/I Lubricant type mineral oil ISO VG 220 Oil grade CLP 220 Lubricant quantity (l) 1,000 Shade 7031 Blue-grey Paint type solid color Basic painting instruction (2) CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No |
Please Contact Us to Order to offer competitive prices and delivery time for Nord - SK33-100AP/4 TF helical gear motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
