SK2282AG-90L/8-2 BRE10 Z WU - Nord Malaysia Sales

BRAND	Nord
Product	SK2282AG-90L/8-2 BRE10 Z WU
Description	Flat gear brake motor
Internal code	IMP4804861
Technical specification	Design: as already delivered with the serial number 1004391873.00 Motor speed 640 1/min Motor speed 2 2,770 1/min Translation 45.11 Output speed 14,000 rpm Output speed 2 61,000 1/min Operating factor 2.20 Output torque M2 (Nm) 202.00 Power (kW) 0.300 Power 2 (kW) 1,200 Voltage (V) 400Y/Y Frequency (Hz) 50 Operating mode S3 40% Motor protection class IP55 Insulation class F Current Rating 1 (AMP) 1.31 Current Rating 2 (AMP) 3.05 Cosine 1 0.60 Cosine 2 0.79 M1 gearbox design Case type hollow shaft Wave size 35H7 Open vent, with transport lock Rubber Bumper With Rubber Bumper Silumin runner Silumin runner Terminal box layer/cable insert 1/I Braking torque (Nm) 10 Braking torque adjusted (Nm) 5 Brake tensions 230VWS-205VGS Precima brake supplier Brake protection class IP55 BR55PW Bremse Series Additional flywheel mass Additional flywheel mass Lubricant type mineral oil ISO VG 220 CLP 220 grade oil Lubricant quantity (l) 1,700 Shade 7031 Blue-grey Varnish type solid color Basic painting instruction (2) CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No Spare part rubber buffer/met-rubber

Please Contact Us to Order to offer competitive prices and delivery time for Nord - SK2282AG-90L/8-2 BRE10 Z WU Flat gear brake motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
