SF 6/132 RD - VLFM - Steimel Malaysia Sales

BRAND	Steimel
Product	SF 6/132 RD - VLFM
Description	gear pump
Internal code	IMP4729086
Technical specification	ASF6-132RD151350R A-SF6/132RD-VLFM, pump unit,2-16 bar 7.5 kW, 1500, 400/690 V, 50 Hz, IP55, F, B5, IE3 Siemens AG Material number: 000.001.153.515 Gear pump unit: SF 6/132 RD - VLFM Product no.: ASF6-132RD151350R Dimension sheet: DPA056D-132LFM-R31 Spare part list: DET056132RD--165R Suction and pressure connection: SAE 2 ½ Case parts: EN-GJL-250 (GG-25) Shafts: 16 Mn Cr S 5, hardened Gears, noiseless: EN-GJS-400-15 (GGG-40) helically toothed and ionized Shaft seal: radial shaft seal Elastomers: FKM Storage: multi-layer MD Pumping medium: lubricating oil Viscosity: 50 - 5000 cSt Temperature: 10 - 60°C Flow rate: 185/222 l/min. Pressure: 5 bar Speed: 1450/1740 rpm. pressure relief valve Opening pressure: 8 bar Setting range: 2-16 bar Direction of rotation: right Test run: yes, with HLPD 46 Coupling: BKUA065-2438-301 Pump support with foot: BLF056300168LA21 Three-phase motor: LDM132-04-903 (Birkenbeul) Motor data: Power 1/2:7.5/8.6 kW Speed 1/2:1500/1800 rpm Voltage/frequency 1:400/690 volts at 50 Hz Voltage/frequency 2:460 volts - at 60 Hz Efficiency class: IE3 “Premium Efficiency” additional sign (without IE3) for Voltage/frequency: 380-420/660-720 V at 50/60 Hz 440-480 volts - triangle at 60 Hz Protection class: IP 55 Insulation class: F Design: B 5 Aggregate coating: none Identification plate: ETY924-D/E--PE02

Please Contact Us to Order to offer competitive prices and delivery time for Steimel - SF 6/132 RD - VLFM gear pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
