BRAND | Steimel |
Product | ASF3-50RD-170039R |
Description | pump unit |
Internal code | IMP4533333 |
Custom code | 84136039 |
Technical specification | Gear pump unit: SF 3/50 RD - VLFM Item no.: ASF3-50RD-170039R Dimension sheet: DPA053D-112LFM-R31 Spare parts list: DET053050RD-165R Suction and pressure connection: SAE 1 1/2 Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noise opti.: 16MnCrS5, egh., helical gear Storage: multi-layer Shaft seal: radial shaft seal elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: approx. 70.8/84.9 l/min pressure: 5 bar Speed: 1450/1740 rpm pressure relief valve Setting range: 2-18 bar Opening pressure: 8 bar Rotation direction: right Test run: yes, with HLPD 46 Coupling: BKUA055-1928-301 Bellhousing with foot: BLF053250128LA21 three-phase motor: LDM112-04-903 (Birkenbeul) Engine data: Power 1/2:4.0 /4.6 kW Speed 1/2:1500 /1800 rpm Voltage 1:230/400 volts at 50 Hz Voltage 2:265/460 volts at 60 Hz Efficiency class: IE3 Additional plate (without IE3) for: Voltage: 220-240/380-420 volts at 50/60 Hz : 250-280/440-480 volts at 60 Hz Degree of protection: IP 55 Insulation class: F Design: B 5 aggregate paint: primed HDO058 - green Type plate: ETY924-D-E—PE02 |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF3-50RD-170039R pump unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
