BRAND | Gemü |
Product | R480 50W332A1ELF0305 D09 |
Internal code | IMP4795072 |
Custom code | 8481 8085 |
Technical specification | 88680636 type R480 butterfly valve, free shaft end, body with C5-M coating (min. 250μm) and integrated leakage groove, blow-proof shaft with dust protection, supported several times through a PTFE socket, multiple sealing system with bevel, Material can be read when installed DN 50 DN 50 housing shape W intermediate flange design (wafer), FTF EN 558 series 20 installation length Operating pressure 3 16 bar Connection type 3 PN 16/flange EN 1092, installation length FTF EN 558 series 20 Housing material 2 EN-GJS-400-15 (GGG-40), epoxy coated 250 μm Material disc A 1.4408 Material shaft 1 1.4021 E EPDM barrier seal material Cuff fixation L cuff loose Drive flange F03 F03, flange type DIN EN ISO 5211 Drive flange 05 F05, flange type DIN EN ISO 5211 Wave shape and size D09 square, diagonal, SW 9 mm Wavelength 17 mm DN25 - DN100 PS16 |
Please Contact Us to Order to offer competitive prices and delivery time for Gemü - R480 50W332A1ELF0305 D09 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
