BRAND | Stober |
Product | MV0000203838/S102AF0280IE3D071L04 |
Internal code | IMP4908834 |
Custom code | 85015100 |
Technical specification | MV0000203838 worm gear motor S102AF0280IE3D071L04 Customs tariff number 85015100 (0.00... 0.75kW) Weight 22 kg Frequency range 9.0-50.0 Hz Rated current 0.98 A Translation 27.90 Math. Exact translation 279/10 Engine torque 2.50 Nm Output torque 34-61 Nm Engine speed 1.430 rpm Output speed 9.2-51 rpm Motor power 0.37 kW Load characteristic 2.0 Shaft design Hollow shaft with spring groove Output bearing Reinforced storage Shaft dimension Ø25 v.lag. 93435 Position shaft/ pinion insert side 3 Coverage page 4 Housing design round flange Ø120 94567 output flange mounting side flange side side 3 EL6 installation position Mobile SHC CIBUS220 Lebensm lubrication H1 HCE ISO VG 220 Efficiency class IE3 Number of pins 4-pin Network power 0.37kW Drive controller operation Operation on drive controller Curve inverter 400V 50Hz type point 50Hz Standard version option* Voltage type Wide range voltage + -5% * Frequency 50Hz Voltage 220-240/380-420V Protection class IP56 Thermal class 155 (F) PTC thermistor thermal winding protection Brake brake integrated Cooling type Self-ventilated Operating mode S9 FU mode Terminal box position 90° Left cable entry Brake connection type AC ex. Rectifier in KLK Brake rectifier Powerbox rectifier Braking voltage AC 190-277V PB DC 115V/127V Spring brake torque 5Nm (4Nm) Koro 1 standard brake Encoder type Incremental encoder HTL 1024 encoder pulses K/1-layer painting Color RAL 9007 gray aluminum Painting options Page 3 not painted Documentation language German Documentation language English |
Please Contact Us to Order to offer competitive prices and delivery time for Stober - MV0000203838/S102AF0280IE3D071L04 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
