| BRAND | Interroll |
| Product | MI-DM0080 DM0803-AAC01B0E0FJD-300mm |
| Internal code | IMP4580961 |
| Technical specification | Product name DM 0080 Asynchronous 3-phase IP 69K degree of protection Tube length (SL) 293.0 mm Drum width (FW) 300.0 mm Installation length (EL/LW/BF) 305.0 mm Overall axle length (AGL) 330.0 mm power 140 W winding number of poles 2 Torque [Nm] 8.9 strip tensile force 219 N Gear ratio (i) 20.27 gearbox material designation steel: 16MnCr5/AISI 5115 Velocity at frequency 1 0.59 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.38 A rated current, low voltage 0.65 A Velocity at frequency 2 0.72 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Tube material stainless steel: 1.4301/304 Pipe diameter (A) 81.5 mm Tube diameter (B) 80.5 mm Pipe shape crowned (standard) Lid A design standard Lid B version standard Lid A material aluminium: EN-AC43400/AL239 lid B material aluminium: EN-AC43400/AL239 Shaft A version standard Ø17mm Shaft B version standard Ø17mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Shaft A Key.Area width (F) 13.5 mm Shaft B Key.Area width (F) 13.5 mm Wave A key. Face length (C) 12.5 mm Wave B key. Face length (C) 12.5 mm Oil type synthetic food oil Electrical connection straight screw connection electric. Connection material brass CuZn39Pb3/MS58 Power cable length 5.0 m Power cable type unshielded; non-halogen free |
Please Contact Us to Order to offer competitive prices and delivery time for Interroll - MI-DM0080 DM0803-AAC01B0E0FJD-300mm number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
RD-35NGJABN90 RL: 360;AGL: 400
(Net weight: 15.33 KG ReDesign series Serie3500Festantriebsrolle Redesign RL -Rollenlänge 360.0 mm EL - Installation length: 400.0 mm AGL - of shaft 400.0 mm Bearing Prz.LagerStahlblankfett2RZ Übertriebsart hard drive drive element flat belt head PA 38 mm Galvanized steel tubing Tube outside diameter 60.0 mm pipe wall thickness 1.5 mm antistatic execution antistatic Axle material Steel Bright axle diameter 14.0 mm Shaft lengths links 0,0 mm Shaft lengths at right 0.0mm Axis version 1 internal thread on both sides M8x15 Achsausführungslänge 1 Links 0.0 mm Achsausführungslänge one right 0.0mm Achsausführungslänge 2 links 0.0mm Achsausführungslänge 2 Right 0.0 mm)
roll return team
RD-35XQKJ8N91 RL: 800;AGL: 862
Serie3500Festantriebsrolle
FRICTION ROLLER
FRICTION ROLLER
cone ROLLe,Chain gears STEEL
BU Conveyor Tracks Castor Rail Series caster kit BU40 BU Role Selection mounted Role Type rolls PP 2 row 8mm + Ring Total length 1976.0 mm First position roll 26.0 mm Division 104.0 mm Last Position Role 78.0 mm Distance length 1872.0 mm Number of rolls 19
RD-BU BU CONVEYOR TRACKS 520,0 MM ROLLENSCHIENE BU40
BU Role Selection mounted Role Type 2201 Overall length 520.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Displacement Length 468.0 mm
BU Role Selection mountedRole Type 2201Overall length 572.0 mmFirst position roll 26.0 mmPitch 52.0 mmPosition last role 26.0mmDisplacement Length 520.0 mm
RD-BU BU CONVEYOR TRACKS ROLLENSCHIENE BU40 1.976,0 MM
Castor Rail Series caster kit BU40 BU Role Selection mounted Role Type 2201 Total length 1976.0 mm First position roll 26.0 mm Pitch 52.0 mm Position last role 26.0mm Distance length 1924.0 mm Number of rolls 38
DIMENSIONS FOR 2 POLYMER SPROCKETS
BTU GZ SP 25,4 MS 44,5 M12X25
PH ZWEIREIHIG ROELLCHEN 6,5x24x48 SW
S-64000376 AA; SY0033; CR2130; 48,00 MM; 6,50 MM; 2
PLASTIC ROLLER BEARING BLUE
diameter will be 30 mm, the inner diameter of 8 mm. Metal components inside diameter is the inner diameter.
