BRAND | Jesco |
Product | LA 150 PP/FPM |
Description | Motor-Driven Diaphragm Dosing Pump |
Internal code | IMP4641736 |
Custom code | 84135040 |
Technical specification | Article-Nr. 10412007 Product: MEMDOS Type: LA Delivery rate: 156 l/h at 50/60 Hz against max. 5 bar Material dosing head and valves: PP Electric drive: 230 V 1ph 50/60 Hz 0.37 kW with motor 0.18 kW Electric connection: 1.8 m mains cable with plug, Europe (for 230 V AC) Suction valve: DN10 double-ball ceramic/FPM (ball/gasket) Discharge valve: DN10 double-ball ceramic/FPM (ball/gasket) Material suction connection: PP Suction connection: Hose clamp connection 13/20 Material discharge connection: PP Discharge connection: Hose clamp connection 13/20 Functions Stroke frequency adjustable via potentiometer 0 - 100 % Signal-LED's for status, operation and error indication Analogue input 0/4 –20 mA Level input with main alarm Release input for external start/stop Stroke feedback output Alarm relay output Analogue output 0/4 – 20 mA |
Please Contact Us to Order to offer competitive prices and delivery time for Jesco - LA 150 PP/FPM Motor-Driven Diaphragm Dosing Pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
