BRAND | Stober |
Product | K303AF0390ME20 |
Description | bevel gear with motor adapter |
Internal code | IMP4820457 |
Custom code | 84834023 |
Technical specification | Replaces serial number: 10596716 MV0000127681 bevel gear with motor adapter Translation 39.19 Math. Exact translation 34916/891 Rated torque 350 Nm Max. Permissible Acceleration torque 385 Nm Max. input speed duration 3,700 rpm Engine speed 1,500 rpm Max. input speed cycle 6,000 rpm Shooting game 10 arcmin Load characteristic value 1.0 Shaft design hollow shaft with keyway Shaft size Ø35 *90178 Shaft/sprocket position insert side 4 Housing design round flange Output flange Ø200 c2=38 *90023 Fastening side flange flange page 4 Installation position EL1 Coupling type clamp coupling Motor shaft diameter 22 without key Maximum motor wavelength min. 35 mm - max. 61 mm Two-piece clutch housing design (for motor plate) Motor connection □ 140 110/145 M8 c=32 *215014 270° clamp screw access Single drive shaft seal FKM MSS-1 HS Mobil SHC CIBUS220 Lifetime Lubrication H1 HCE ISO VG 220 W lacquering/2-layer coating Color RAL 9005 deep black Painting options Completely painted Documentation language French |
Please Contact Us to Order to offer competitive prices and delivery time for Stober - K303AF0390ME20 bevel gear with motor adapter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
