K102AG0175IE3D080L04 - Stober Malaysia Sales

BRAND	Stober
Product	K102AG0175IE3D080L04
Description	bevel gear motor
Internal code	IMP4935707
Custom code	85015100
Technical specification	Frequency range 9.0-50.0 Hz Rated current 1.70 A Translation 17.56 Math. Exact translation 2090/119 Engine torque 5.00 Nm Output torque 49-85 Nm Engine speed 1.445 rpm Output speed 15-82 rpm Motor power 0.75 kW Spin 12 arcmin Load characteristic 1.3 Shaft design Hollow shaft with spring groove Shaft dimension Ø25 95403 Position shaft/ pinion insert side 4 Threaded hole circuit housing design EL6 installation position Mobilgear 600 XP 220 lubrication CLP ISO VG 220 Efficiency class IE3 Number of pins 4-pin Network power 0.75kW Drive controller operation Operation on drive controller Curve inverter 400V 50Hz type point 50Hz Standard version option* Voltage type Wide range voltage + -5% * Frequency 50Hz Voltage 220-240/380-420V Protection class IP56 Thermal class 155 (F) PTC thermistor thermal winding protection Cooling type Self-ventilated Operating mode S9 FU mode Terminal box position 270° Right cable entry Encoder type Incremental encoder HTL 1024 encoder pulses Encoder connector Yes K/1-layer painting Color RAL 9005 deep black Painting options page 4 not painted

Please Contact Us to Order to offer competitive prices and delivery time for Stober - K102AG0175IE3D080L04 bevel gear motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
