| BRAND | Stahl |
| Product | ET-208-TX-W00-DC-GL / 243335 |
| Description | Raptor device platform |
| Internal code | IMP3852041 |
| Weight | 4 |
| Custom code | 84714108 |
| Technical specification | ET-208-TX-40103000003-000500000000 field system consisting of: 236504 Operator Interface 200 SERIES Raptor device platform Tipo: ET-208-TX-W00-DC-GL Technology: RAPTOR Operator Interface Range of use (zones): 1, 2, 21, 22 Display version: Sunlight readable Backlight: LED technology Display size inches: 7 Display size cm: 18 Display resolution: WVGA 800 x 480 pixels Display format: 15:9 Display brightness: 500 cd/m2 Touch screen: capacitive Touch screen material: glass Front panel: glass on aluminum Front design: front installation Processor type: Cortex A8, 800 MHz RAM: 512 MB Data storage: 1 GB Media interface: 10/100BaseTX (Ex e) Maximum cable length: max. 100 m Connector type: terminals Serial interface: 1xRS422/485, 1xRS422 (Ex e) USB interface: 1 x USB Ex ib, 1 x USB Ex e Integrated audio amplifier: No Heating available: Yes Operating system: to be specified Operating voltage: 24 VDC Ambient temperature °C: -40... 70 °C Ambient temp. Continuous operation: +65 °C 290mm x 146mm x 83mm Case protection type (IP) front: IP66/IP69 housing protection. (IP) Back: IP54 Certifications & Approvals: ATEX China (CNEX) Korea (KCC) Korea (KGS) China (CCC) IECEx India (BIS) United Kingdom (UKCA) Russia (EAC) NEC CEC India (PESO) Model BIS: ET-208-TX-W00-DC-GL Gas explosion protection: II 2 G Ex eb ib q [ib] IIC T4 Gb Dust explosion protection: II 2 D Ex tb ib [ib] IIIA T115°C Db For more information, see: r-stahl.com Webcode ET208A 236528 SPlusRT 200 SPSPlusWIN Runtime for 200 series Note: requires SPSPlusWIN version 6x or newer 236527 WEC7 Windows® Embedded Compact 7 Languages: en image on the device/drive Certificate of Authenticity on the back of the case Licence information in the operating instructions FSB RU0000046423 SPSPlusWIN 6 license |
Discover the superior quality and performance of the Stahl ET-208-TX-W00-DC-GL / 243335 with Impexron GMBH in Malaysia. Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ET-208-TX-W00-DC-GL / 243335 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ET-208-TX-W00-DC-GL / 243335:
At Impexron GMBH, we offer the ET-208-TX-W00-DC-GL / 243335 at competitive prices and with the fastest delivery times across Malaysia. Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH?
Get Your Quote Today! Ready to enhance your operations with the ET-208-TX-W00-DC-GL / 243335? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
You can purchase :product by :brand from Impexron GMBH.We serve customers across the Malaysia, offering competitive prices and reliable service.
What is the price of :product?
For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.
While we are not the official distributor or seller of :brand in the Malaysia, we source our products from reliable channels and offer you original :brand equipment at competitive prices.
You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.
We can assist you in contacting the manufacturer to ensure you receive the support you need.
P/N: 145317, Type: 8493/11-21-6
signaling device
SAFETY SWITCH/ 25 A, 3-POLE
P/N: 149135, Type: 8560/51-4061
small safety element
P/N:149164, Type: 8560/51-4222
Small fuse element
P/N: 150598, Type: 8570/11-304
Switch socket
Switch socket
Switch socket
(Switch socket explosion proof)
P/N: 150494, Type: 8570/11-506
Switch socket
3X16 A EX PROOF PLUG
plug
Plug explosion-proof
(Plug explosion Proof Type: 8570 / 12-406 Bemessungsbetr.spg. / Frequency: 380-415 V 50/60 Hz Operating current: 16 A Detailed Contacts 4 P (3 P + PE) Color code: red Coding (time position): 6 Housing material: Polyamide Field of Application (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex de IIC T6 Dust explosion protection: II 2 D IP66 80 ° C Ambient temperature min. : -30 ° C Ambient temperature max. +55 ° C Protection (IP): IP66 Terminals: 1.5 mm Cable entry: 8 ... 20 mm plug explosion proof)
P/N: 150854, Type: 8571/11-506
switch socket
PLUG,UTILITY, 2-POLES
p/n: 270900, Type: 8579/31-506
Switch socket for low temperature, explosion-proof
Pushbutton
(Button label Label marking : STOP Colour of label : red For further information, see : www.r-stahl.com Web code 8082A)
(Rotary handle, small lockable explosion-protected Enclosure material : Polyamide Seal : Standard Mounting : with threaded Switching function : latching Number of switching positions : 2 Construction type : vertical Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e II Dust explosion protection : II 2 D Ex tD A21 Min. ambient temperature : -50 °C Max. ambient temperature : +70 °C Type of protection (IP) : IP66 For further information, see : www.r-stahl.com Web code 8082A)
8703-PUSH BUTTON ASSEMBLY (OBSOLETE REPLACED BY 8602)
PUSH BUTTON FOR START-NO CONTACT
Single-channel safety barriers explosion-protected
9118/11-11-10 - OBSOLETE (REPLACED BY 9118/11-11-10)
ics modul-mA isolating repeater(max vol.:8.7 V max. cur.:0.4 mA max. pow.:11mW power supp.:24 vDC)
Barrier
BARRIER: PROTECTIVE, for receiving and transmitting UNIFIED SIGNALs POWER SUPPLY SENSOR, EEX IA IIC
mA-Trennübertrager
iSPAC separation transformer
