| BRAND | Stober |
| Product | EK702USABQTP140 |
| Description | servo motor |
| Internal code | IMP3367901 |
| Weight | 15.2 |
| Custom code | 85015220 |
| Technical specification | Standstill current 6.72 A Nominal current 6.40 A Standstill torque 10.65 Nm Motor torque 9.80 Nm Motor speed 3000 1/min Motor power 3.08 kW ED/EK engine type name EK702USABQTP140 Cooling type Convection cooling IC MGS Ø200 PR 130 LK 165 output side RC5 shaft design, Ø18 Drive controller manufacturer STOBER Encoder connector BG/Art STOBER drive controller con.23 DC bus voltage 540V DC bus voltage Drive controller type/ MDS 5000 connection 442561 connection diagram EnDat Multiturn digital encoding method Encoder type Opt. 2.1 EQN 1325 Nominal speed nN 3000 1/min 540V (KEM=140) ED Plug type angle rotatable Connector Without connector Power connector 8-pin con.23 Position of connectors 270° Cable entry links * PTC thermal winding protection in the power connection Ambient temperature -15 to +40°C standard Thermal class (VDE 0530) 155 F Protection class (EN 60529) IP56 (EN 60529) UR/CSA Recognized Components version option 15Nm MBS/12nm MBD/PM 24VDC brake S1 Operating mode Servo Motors 88768 sprocket Module 1.25 teeth 32 Angle of inclination 24° Right flank direction K painting/1-layer painting Color RAL 9005 deep black Painting options output not painted Documentary language German Documentary language English |
Discover the superior quality and performance of the Stober EK702USABQTP140 with Impexron GMBH in Malaysia. Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The EK702USABQTP140 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of EK702USABQTP140:
At Impexron GMBH, we offer the EK702USABQTP140 at competitive prices and with the fastest delivery times across Malaysia. Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH?
Get Your Quote Today! Ready to enhance your operations with the EK702USABQTP140? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stober products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
You can purchase :product by :brand from Impexron GMBH.We serve customers across the Malaysia, offering competitive prices and reliable service.
What is the price of :product?
For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.
While we are not the official distributor or seller of :brand in the Malaysia, we source our products from reliable channels and offer you original :brand equipment at competitive prices.
You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.
We can assist you in contacting the manufacturer to ensure you receive the support you need.
