DBB51CM241M - Carlo Gavazzi Malaysia Sales

BRAND	Carlo Gavazzi
Product	DBB51CM241M
Description	FUNCTION True delay on release OUTPUT SIGNAL 1
Internal code	IMP247416
Weight	1
Technical specification	Timers True Delay onRelease Type DBB51 • Time range 1 to 600 s - capacitor powered • Knob-adjustable time setting • Automatic start after drop-out of power supply • Repeatability: ≤ 0.2% • Output: 5 A SPDT relay • For mounting on DIN-rail in accordance with DIN/EN 50 022 • 17.5 mm DIN-rail housing (DIN 43880) • Combined AC and DC power supply • LED indication for relay status and power supply ON Product Description Ordering key DBB 51 C M24 10M Multi voltage (true) delay on release timer. Time ranges from 1 to 600 s covered by 3 models. Housing 17.5 mm wide suit- able for DIN-rail mounting. Fits in M36 cover. Housing Function Type Item number Output Power Supply Range Type Selection Mounting OutputTime rangeSupply: 24 VDC and 24 to 240 VAC For DIN-rail SPDT1 to 10 sDBB 51 C M24 10S SPDT6 to 60 sDBB 51 C M24 1M SPDT60 to 600 sDBB 51 C M24 10M TimeSpecificationsOutput Specifications Time ranges Type 10 S1to10 s Type 1 M 6to60 s Type 10 M 60to600 s Repeatability ≤ 0.2% Time variation Within rated power supply ≤ 0.05% Within ambient temperature ≤ 0.2% ResetPower supply applied for: DBB51CM2410S≥ 200 ms DBB51CM241M,≥ 200 ms DBB51CM2410M ≥ 400 ms Supply Specifications Power supplyOvervoltage cat. III Rated operational voltage(IEC 60664, IEC 60038) through terminals:A1, A2 24 VDC ± 15% and 24 to 240 VAC +10% -15%, 45 to 65 Hz Voltage interruption≤ 40 ms Rated operational power AC supply: 1.5 VA DC supply: 0.06 W OutputSPDT relay Rated insulation voltage250 VAC (RMS) Contact Ratings (AgSnO2) µ Resistive loadsAC 1 5 A @ 250 VAC DC 12 5 A @ 24 VDC Small inductive loadsAC 15 2.5 A @250 VAC DC 13 2.5 A @24 VDC Mechanical life≥ 30 x 106operations Electrical life ≥ 105operations (at 5 A, 250 V, cos ϕ = 1) Operating frequency< 7200 operations / h Dielectric strength Dielectric voltage2 kVAC (RMS) Rated impulse withstand voltage2.5 kV (1.2/50µs) Specifications are subject to change without notice (02.04.08)1

Please Contact Us to Order to offer competitive prices and delivery time for Carlo Gavazzi - DBB51CM241M FUNCTION True delay on release OUTPUT SIGNAL 1 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
