BAR14.X1HA1GP3, eID: DE50912006 - Vega Malaysia Sales

BRAND	Vega
Product	BAR14.X1HA1GP3, eID: DE50912006
Description	Process pressure transmitter
Internal code	IMP2029911
Weight	1.04
Custom code	90262020
Technical specification	with ceramic measuring cell Application: The VEGABAR 14 is a universal pressure transducer for the measurement of gases, vapors and liquids. The VEGABAR 14 is a cost-effective solution for a wide range of applications in all industrial sectors. Your benefit - High plant availability due to the highest overload and vacuum resistance of the ceramic measuring cell - Cost-effective design with smallest installation dimensions - Low maintenance and maintenance costs due to wear-free ceramic measuring cell Approval Guideline /scope : None / worldwide Approval .X: without Pressure type / measuring range 1H: rel. / 0 ... + 25 bar (0 ... + 2500 kPa) Electrical connection / protection A1: 4-pin connector ISO4400, PG9 / IP65 Process connection / Material GP: Thread G½, inside G¼ PN60, ISO228-1 / 316L Sealing concept / media contact Seal / process temperature 3: Single / EPDM (A + P 75.5 / KW75F) / -40 ... + 100 ° C Measuring range Final value: 25,000 Operating instructions: DE - English Number of operating instructions: 2 Total net weight in kg: 1.04 Customs tariff number (HS code): 90262020

Please Contact Us to Order to offer competitive prices and delivery time for Vega - BAR14.X1HA1GP3, eID: DE50912006 Process pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
