BRAND | Steimel |
Product | ASF4-112RD161410R |
Description | A-SF4/112RD-VLFM, pump unit, 2-16 bar |
Internal code | IMP4307729 |
Custom code | 84136039 |
Technical specification | 7.5 kW, 1500, 400/690V, 50Hz, IP55, F, B5, IE3, special build 1) 10 weeks Gear pump unit: SF 4/112 RD - VLFM Item no.: ASF4-112RD161410R Dimension sheet: DPA054D-161410R Spare parts list: DET054112RD—165R Suction & pressure connection: SAE 2 Chassis parts: EN-GJL-250 (GG-25) Waves: 16 Mn Cr S 5, egh. gears, noise opti.: EN-GJS-400-15 (GGG-40), ionitrated, helical Storage: multilayer MD Shaft seal: radial shaft seal Elastomers: FKM Conveying medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C flow rate: approx. 140/ 168 l/min. pressure: 5 bar Rotational speed: 1450 /1750 rpm pressure relief valve Opening pressure: 8 bar Setting range: 2-16 bar direction of rotation: right Trial run: yes, with HLPD 46 coupling: BKUA065-2438-301 Pump carrier with foot: BLF054300168LA21 three-phase motor: LDM132-04-074 (birkenbeul) Engine data: power 1/2:7.5/8.6 kW speed 1/2:1500/1800 rpm Voltage/frequency 1:400/ 690 volts at 50 Hz Voltage/frequency 2:460 volts at 60 Hz Efficiency class: IE3 with additional sign (without IE2) for Voltage/frequency: 380-420/660-720 V at 50/60 Hz 440-480 volts at 60 Hz Protection class: IP 55 Insulation class: F Design: B 5 Paint: primer HDO058 green Nameplate: ETY924-D-E—PE02 * building site: Engine terminal box: rotated 90° to the left at view of the motor shaft. pump: rotated 90°, suction connection down direction pump foot Engine nameplate: readable from above |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF4-112RD161410R A-SF4/112RD-VLFM, pump unit, 2-16 bar number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
