ASF2-20RD-170046R - Steimel Malaysia Sales

BRAND	Steimel
Product	ASF2-20RD-170046R
Description	pump
Internal code	IMP2056658
Weight	1
Custom code	84136039
Technical specification	A-SF2/20RD-VLFM 2-20 bar 1.5 kW, 1500, 230/400 V, 50 Hz, IP55, F, B5, IE3 Length 623.00 mm Width 210.00 mm height 240.00 mm gear pump unit Item number ASF2-20RD-170046R Dimension sheet DPA052D-090LFM-R33 Spare parts list DET052020RD-165R Suction and pressure connection G 1/SAE 1 Housing parts EN-GJL-250 (GG-25) Pinion shafts, noise-opti. 16MnCrS5, egh., helical gear Storage multi-layer shaft seal radial shaft seal Elastomers FKM Lubricating oil pumping medium Viscosity 50-5000 cSt Temperature 10-60°C Flow rate 28.5/34.5 l/min. pressure 5 bar Speed 1450/1750 rpm. pressure relief valve Setting range: 2-20 bar opening pressure 8 bar Direction of rotation right Test run yes, with HLPD 46 Coupling BKUA040-1424-301 bellhousing with foot BLF052200110LA21 LDM090-04-904 three-phase motor (Birkenbeul) Engine data: Power 1/2 1.5 /1.7 kW Rotational speed 1/2 1500/1800 rpm Voltage 1 230/400 volts at 50 Hz Voltage 2 265/460 volts at 60 Hz Efficiency class IE3 Degree of protection IP 55 Insulation class F design B 5 with additional plate (without IE3) for: Voltage/frequency 220-240/ 380-420 volts at 50/60 Hz 250-280/440-480 volts at 60 Hz aggregate paint primed Type plate ETY924-D/E—PE02 Dimensions LxWxH [mm] 623x 210x 240

Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF2-20RD-170046R pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
