70590533 - Demag Malaysia Sales

BRAND	Demag
Product	70590533
Internal code	IMP3400274
Weight	107.2
Custom code	85030099
Technical specification	LIFTING MOTOR SET ZBR132D12/2V1 Product details Part no. 70590533 customs tariff 85030099 product group ropehoist model range DR size 10 net weight 107,2 kg PUG 5137 Included parts (44) Item Product Units 1 End shield ZBR132 DR5/10 1 EA 2 End shield B140 ZBR132 1 EA 3 Rotor ZBR132D12/2 Iko 1 EA 4 Fan cover long ZB132 1 EA 5 Mounting parts ZB132-B140 1 EA 6 Terminal box cover Z132 -225 1 EA 7 Stator connection ZBR132 1 EA 8 Grooved ball bearing 6209 2Z HTF2 1 EA 9 Retaining ring 85X3 1 EA 10 Grooved ball bearing 6207 2Z HTF2 1 EA 11 Fan impeller light Z 132 1 EA 12 Oil seal A 45X 62X 7 1 EA 13 Cover disk 45X62X4,5RB45 1 EA 14 Magnet body B140 180V 1 EA 15 Stop disk B140 1 EA 16 Damping plate B140 1 EA 17 Collar pin B140 A2-70 MK 3 EA 18 Anchor plate G/B140 1 EA 19 Engaging element B140-ZB132 1 EA 20 O-ring 60 X 2,5 N 1 EA 21 Washer 12 special 3 EA 22 Spring brake Weiss B140 6 EA 23 Spring spacing B140 3 EA 24 Masking tape B140 1 EA 25 Brake disk FB1121 1 EA 26 Stud micro-switch 1 EA 27 Holder parts microswitch 1 EA 28 Microswitch V4NOS 1 EA 29 Oil seal AS 30X 52X 7 1 EA 30 Stator ZBR132D 12/2 1 EA 31 Pulse wheel EG Z132 1 EA 32 Unit IMP RS422 10-30V 1 EA 33 Built-in pulse encoder EG/Z132 1 EA 34 Supporting plate 30X 52X0,5 1 EA 35 Terminal block module ZBR 1 EA 36 Mounting plate ZBR100/132 1 EA 37 VDR resistor insulated 1 EA 38 VDR resistor 401-500V 1 EA 39 Rating plate LAYOUT USA 1 EA 40 Patch cord ZBR132D2/12 1 EA 41 Motor interfer.suppression RC-3 1 EA 42 Plug-in pinion Z 11 M2 B 44 1 EA 43 Gearbox seal A50/A60 1 EA 44 Lock nut M12 VB.RIPP 4 EA

Please Contact Us to Order to offer competitive prices and delivery time for Demag - 70590533 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
