| BRAND | Stahl |
| Product | 267074 / 6002/4148-0100-152-1110-11-8500 |
| Description | Lighting Linear luminaire |
| Internal code | IMP5057765 |
| Custom code | 94054231 |
| Technical specification | Type: 6002/4148-0100-152-1110-11 -8500 Replacement of type: 6002/2284-5400-5131-0 6002/1284-5400-5131-0 Light tray: clear Tub material: polycarbonate Case material: polyester resin Design: standard version Housing colour: light grey (RAL 7035) Range of use (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex db eb ib op is IIC T4 Gb Dust explosion protection: II 2 D Ex tb op is IIIC T100 °C Db Number of lamps: 1 Light power: 42 W Light distribution: 120°x120° with diffuser Luminous flux: 5,810 lm Luminaire efficiency: 138 lm/W Luminaire efficiency DC operation: 50% DC Light color: 5000K - neutral white Color temperature: 5,000 K LED lifespan: L90B50 ≥ 100,000 h Operating device lifetime: C10 ≥ 100,000 h, Ta ≤ 50 °C Maximum solid wire connection: 6 mm2 Max. fine-stranded connection: 4 mm2 Dimensions (L x W x H): 1310 x 184 x 125 mm Rated operating voltage AC: 100.00 - 240.00 V Rated operating voltage DC: 110.00 - 250.00 V Min. ambient temperature: -40 °C Max. ambient temperature: +50 °C Note through wiring: max. 3x16 A Maximum ambient temperature.2: +60 °C Note Through-wiring 2: max. 3x10 A Impact resistance (IEC 62262): IK10 Diffuser: with diffuser Through-wiring: with 5 2.5 mm2 conductors Ballast: 6045/311-120-10 Thread plate: 2x plastic Holes: 3 x M25 settled Cable and cable entries: 2 x M25 Ø 7 — 17 mm Cable entry material: black polyamide Sealing plug: 2 x M25 x 1.5 Sealing plug material: black polyamide Terminal block installed: PE + N + L1 + L2 + L3 Documentation languages: German English Sign languages: German English french For more information, see: r-stahl.com Webcode 6002D |
Discover the superior quality and performance of the Stahl 267074 / 6002/4148-0100-152-1110-11-8500 with Impexron GMBH in Malaysia . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 267074 / 6002/4148-0100-152-1110-11-8500 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 267074 / 6002/4148-0100-152-1110-11-8500 :
At Impexron GMBH , we offer the 267074 / 6002/4148-0100-152-1110-11-8500 at competitive prices and with the fastest delivery times across Malaysia . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 267074 / 6002/4148-0100-152-1110-11-8500 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 267074 / 6002/4148-0100-152-1110-11-8500 by Stahl in Malaysia?
You can purchase 267074 / 6002/4148-0100-152-1110-11-8500 by Stahl from Impexron GMBH. We serve customers across Malaysia, offering competitive prices and reliable service.
What is the price of the 267074 / 6002/4148-0100-152-1110-11-8500?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Stahl in Malaysia?
While we are not the official distributor or seller of Stahl in Malaysia, we source our products from reliable channels and offer you original Stahl equipment at competitive prices.
How can I access 267074 / 6002/4148-0100-152-1110-11-8500 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 267074 / 6002/4148-0100-152-1110-11-8500 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 267074 / 6002/4148-0100-152-1110-11-8500?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
