BRAND | Südmo |
Product | 2008763 / T32504 |
Description | safety valve |
Internal code | IMP4897224 |
Custom code | 84819000 |
Technical specification | compliant Pressure Equipment Directive Cat. IV Type: T32504 Nominal size: DN 040 Inlet: DIN 11853-BS 41x1.5-1.4404-H2 collar Groove union nut DIN11851-F40-1.4301 Outlet: DIN11853-GS 53x1.5-1.4404-H2 thread connector Media: vapors, gases and liquids Adjustment range: 0.5-5.0BAR (7.3-73PSI) Set pressure: X.XBAR (XXPSI) can be adjusted downwards Ventilation: manual Seals: EPDM (FDA/EG1935) Materials in contact with the product: 1.4404 (AISI 316L) Surfaces: Inlet (pressure side): Ra <= 0.8 μm Outflow: Ra <= 1.6 μm (excluding weld seam to flange inlet/outlet) with sealing |
Please Contact Us to Order to offer competitive prices and delivery time for Südmo - 2008763 / T32504 safety valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
