BRAND | Jesco |
Product | 12500235 |
Internal code | IMP4445609 |
Custom code | 84811099 |
Technical specification | pressure hold/overflow valve DN6 PN16 4/6, 6/9, 6/12 PVC/PTFE/EPDM/FPM Q=75 L/H Mathcode:0125D0006CDB016C1ZC1Z00000B Pressure holding and overflow valves Product: pressure hold and overflow valve Type: spring loaded Nominal diameter: DN6 Nominal flow: 75 l/h with uniform flow (DN6) Housing material: PVC Membrane material: EPDM PTFE coated Seals material: EPDM and FPM Nominal pressure: PN16 Input connection material: PVC Input connection: hose clamp connection set 4/6, 6/9 and 6/12 Output connection material: PVC Connection output: hose clamp connection set 4/6, 6/9 and 6/12 Additional equipment/special version: without Preset blow-off pressure: without Adjustment range: 0.5 - 16 bar Ges. weight: approx. 0.7 kg Dimensions (LxWxH): 30x23x17 cm |
Please Contact Us to Order to offer competitive prices and delivery time for Jesco - 12500235 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Malaysia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
